Application Model
SONY E-mount | A7、A7ll(A7M2)、A7lll(A7M3)、A7lV(A7M4)、A7R、A7Rll(A7RM2) 、A7Rlll(A7RM3) 、A7RlV(A7RM4)、A7RV(A7RM5)、A7S、A7SII(A7SM2) 、A7SIII(A7SM3)、A7C、A9、A9II、A9III、A1、ZV-E1、A7C2、A7CR ,etc. |
GFX-mount | GFX50S、GFX50R、GFX50SII; GFX100、GFX100S、GFX100II ,etc. |
MTF & Optical Design


Specification
Note: Tilt and Shift cannot be used simultaneously
| Focal length | 17mm | Maximum aperture | F4 |
| Closest focus distance | 0.3m | Minimum aperture | F16 |
| Frame | Full Frame | Diaphragm Blades | 10pcs |
| Filter size | not support | Optical Design | 17 Elements in 11 Groups |
| Angle of view | 104° | Focus method | MF |
| Weight | Around 1051~1056g | Mount | E/Z/RF/L/GFX |
| Tilt | ±8° | Shift | ±8mm |
| Rotation Angle | 360°(Not available on GFX) | ||
| Size | ![]() | ||
Video
With shift: buildings appear straight and vertical
Without shift: buildings tilt and distort
With shift: buildings appear straight and vertical
Without shift: buildings tilt and distort
With the ±8mm shift capability of an ultra-wide tilt-shift lens, the perspective distortion can be easily corrected, keeping architectural lines straight and vertical.
The image circle of TTARTISAN 17mm F4 Tilt-Shift lens is larger than that of medium format lenses, Approx. 64mm;
Full-frame lens image circle, Approx. 43.2mm;
Medium-format lens image circle, Approx. 54.8mm.
Outstanding coma and color control
TILT FOR A
Miniature World
The TTArtisan Tilt-Shift 17mm F4 lets you transform reality into a miniature world with a simple tilt. The striking visual effect grabs attention and drives engagement on social media.
10 Aperture Blades
Featuring 10 aperture blades for smooth bokeh and the iconic 10-point starburst.
ULTRA-WIDE Portraits
Compared with telephoto lenses that create shallow depth-of-field portraits, the TTArtisan Tilt-Shift 17mm F4 opens up new creative possibilities.
Comes with a
Dedicated Lens Hood
It helps reduce unwanted light and provides extra protection for the front element, minimizing the risk of bumps and scratches.
Vignetting Notes
With Shift (GFX Mount)

With shift & lens hood: slight vignetting (GFX Mount)
More Details
Weighs approx. 1051–1056g
All-metal body (with clicked aperture ring)
360° Rotation (15° click stops)
Tilt & Shift Mechanism

Package List
| Picture | Listing | Quantity |
| Tilt-Shift 17mm F4 ASPH. Lens | *1 |
| Lens Hood | *1 |
| Front Cap | *1 |
| Rear Cap | *1 |
| Box | *1 |
| User Manual | *1 |
| Warranty Card | *1 |
